MANASLU
Suspended decorative luminaire for LED light sources.



Unique design

Application

boutiques, car showrooms, conference rooms, offices, reception desks, shopping centers

Luminous flux range

560 - 600 [lm]

Variable color temperature

3000 - 4000 [K]

Mechanical data

Mounting
suspended, on wire suspension (included)
Body colour
gray, light gray
Detail
red
Operating temperature range
0˚C ... +35˚C
Body
architectural concrete, steel

Electrical data

Power
220-240V 50/60Hz
Includes light source
yes
Luminaire power [W]
8
Output current [mA]
700
Type of equipment
ED

Optical data

Way of lighting
direct
Type of optic
lens
Colour temperature [K]
3000, 4000
Beam angle
52°
CRI/Ra
≥80
Lumen luminaire [lm]
560 - 600
Efficacy [lm/W]
70 - 75

General data

Lifetime L70B50
100 000 h
Lifetime L80B10
60 000 h
Warranty
5 years

Dimensions

Dimensions [mm] LxD1xD2 Pallet quantity Net weight [kg]
470x100x120 30 4.5
X

Available variants

Code
Colour temperature [K]
3000
4000
Lumen luminaire [lm]
Luminaire power [W]
Efficacy [lm/W]
Body colour
gray
light gray
Clear Filters
Compare Code Type of equipment Beam angle Luminaire power [W] Lumen luminaire [lm] Efficacy [lm/W] Colour temperature [K] CRI/Ra
260030.5L01.111 ED 52° 8 560 70 3000 ≥80
260030.5L02.111 ED 52° 8 600 75 4000 ≥80
260040.5L01.111 ED 52° 8 560 70 3000 ≥80
260040.5L02.111 ED 52° 8 600 75 4000 ≥80
Compare selected
Designed by LUG Design Team
Luminous flux tolerance +/- 10%.
Power tolerance +/- 5%.
Lighting beam, light intensity distribution and light efficiency were examined in accordance with the EN ISO 17025:2005 norm for EN13032 norm series and the LM-79 norm.
Up-to-date product info available on our website www.flashdq.com
Detailed information on luminous fluxes and powers for individual indexes are indicated on the product data sheet.
The parameters in the data sheet are given for Ta=25°C.
Colour temperature tolerance +/- 5%.
