ATLANTYK 2.0 BASIC LED

Product description

Technical parameters

To download

Accessories

Explore services Customisation Support and contact

Other parameters available View variants

ATLANTYK 2.0 BASIC LED

Hermetic LED luminaire, water-jet proof, intended for mounting inside industrial or architectural objects.

High efficacy to 181 lm/W

Maintenance-free operation

Perfect combination of aesthetics and ergonomics

The ideal luminaire for tough working conditions

Possible illuminance control

Available in a variety of options

Fast and easy mounting

Modern design

Reliability

Passive cooling system

Simple one person mounting

Application

assembly halls, electricity plants, mills, parking areas, production halls, warehouses, warehouses, wood and paper industry, workshops

Available on request

available with connection to a central battery power supply, radar motion detector, twilight sensor

Luminous flux range

2900 - 16500 [lm]

Variable color temperature

4000 [K]

Mechanical data

Mounting

suspended, on chains, on wire suspension (on request), directly on the ceiling, with mounting brackets (included), on the wall vertically (connector downwards) with mounting brackets (included), on the wall horizontally with mounting brackets (on request)

Body colour

graphite, light gray, red

Operating temperature range

-20 ... +30, -20 ... +35, -25 ... +30, -25 ... +35, 0 ... +35

RAL

3020, 7024, 7035

Body

polycarbonate

Type

High Efficacy, High Lumen Output, low assembly

Electrical data

Power supply efficiency

≤90%

Power

220-240V 50/60Hz

Includes light source

yes

Luminaire power [W]

18 - 99

Output current [mA]

250, 300, 320, 350, 390

Type of equipment

DALI, DALI + through wiring (TW) 5x1,5 mm², STANDARD, STANDARD + through wiring (TW) 5x1,5 mm²

Maximum number of luminaires in the circuit with a 10A fuse (B)

10 - 35

Maximum number of luminaires in the circuit with a 16A fuse (B)

17 - 56

Maximum number of luminaires in the circuit with a 25A fuse (B)

Optical data

Way of lighting

direct

Type of optic

opal diffuser

Diffuser

polycarbonate

Colour temperature [K]

4000

CRI/Ra

≥80

MacAdam's steps

Lumen luminaire [lm]

2900 - 16500

Efficacy [lm/W]

132 - 181

Photobiological risk group

RG0

General data

Additional information

CRI/Ra ≥80, EASY CONNECT

Other remarks

in order to apply the luminaire in an aggressive environment a consultation with the LUG Technical Preparation of Production Branch is required

Lifetime L80B10

100 000 h; 85 000 h - High Efficacy ; 50 000h - High Lumen Output

Warranty

5 years

Dimensions

Dimensions [mm] LxWxH	Mounting dimensions [mm] D	Pallet quantity
1245x100x90	766	105	1.7
1245x100x90	766	105	1.8
1245x100x90	766	105	2.4

Available variants

Code	Type of equipment	IK	Body colour	Luminaire power [W]	Lumen luminaire [lm]	Efficacy [lm/W]	Operating temperature range	Emergency operating time
090380.3L02.011	DALI	IK08/IK10*	light gray	31	4700	152	-25 ... +35	-
090380.3L02.011.938	DALI + through wiring (TW) 5x1,5 mm²	IK08/IK10*	light gray	31	4700	152	-25 ... +30	-
090380.3L02.021	DALI	IK08/IK10*	graphite	31	4700	152	-25 ... +35	-
090380.3L02.021.938	DALI + through wiring (TW) 5x1,5 mm²	IK08/IK10*	graphite	31	4700	152	-25 ... +30	-
090380.3L02.031	DALI	IK08/IK10*	red	31	4700	152	-25 ... +35	-
090380.3L02.031.938	DALI + through wiring (TW) 5x1,5 mm²	IK08/IK10*	red	31	4700	152	-25 ... +30	-
090380.3L04.011	DALI	IK08/IK10*	light gray	40	6250	156	-25 ... +35	-
090380.3L04.011.938	DALI + through wiring (TW) 5x1,5 mm²	IK08/IK10*	light gray	40	6250	156	-25 ... +30	-
090380.3L04.021	DALI	IK08/IK10*	graphite	40	6250	156	-25 ... +35	-
090380.3L04.021.938	DALI + through wiring (TW) 5x1,5 mm²	IK08/IK10*	graphite	40	6250	156	-25 ... +30	-

Compare selected

Shown 10 / 83

Show all

The luminaires are not intended for mounting in places exposed to atmospheric conditions, in car washes, in rooms where washing with pressure washers is used, in livestock rooms, in aggressive environments, etc.
In order to apply the luminaire in an aggressive environment, for example with an increased concentration of sulfur, salt or other aggressive substances, a consultation with the LUG Technical Preparation of Production Branch is required.
Luminous flux tolerance +/- 10%.
Power tolerance +/- 5%.
Up-to-date product info and General Warranty Terms available on our website www.luglightfactory.com
Detailed information on luminous fluxes and powers for individual indexes are indicated on the product data sheet.
The parameters in the data sheet are given for Ta=25°C.
Colour temperature tolerance +/- 5%.
* Mechanical resistance IK10 only when using an accessory: 150020.01187
