LUGTRACK SLIM LED

Product description

Technical parameters

To download

Accessories

Explore services Customisation Support and contact

Other parameters available View variants

LUGTRACK SLIM LED

The luminaire dedicated to illuminate supermarkets, retail space, warehouse and industrial facilities. The product is characterized by a slim design and very good technical parameters. It is available in two lengths and colour versions. It can be used in applications for hanging on chains or on a cord.

High efficacy to 151 lm/W

Universal design

Perfect for retail lighting

Fast and easy mounting

Application

logistics centers, production halls, supermarkets, warehouses

Luminous flux range

8600 - 17200 [lm]

Variable color temperature

4000 [K]

Mechanical data

Mounting

suspended, on chains (on request), on wire suspension (on request)

Length [mm]

1512, 3010

Body colour

black, white

Operating temperature range

0˚C ... +35˚C

Body

coated steel sheet

Type

Optical module

Electrical data

Power supply efficiency

≤93%

Power

220-240V 50/60Hz

Includes light source

yes

Luminaire power [W]

57 - 115

Output current [mA]

350, 700

Type of equipment

DALI, ED

Optical data

Way of lighting

direct

Diffuser

polycarbonate

Colour temperature [K]

4000

CRI/Ra

≥80

Lumen luminaire [lm]

8600 - 17200

Efficacy [lm/W]

150 - 151

General data

Other remarks

through wiring 5x1,5mm (as a standard), connector (1 pcs.)

Lifetime L80B10

100 000 h

Warranty

5 years

Dimensions

Dimensions [mm] LxWxHxD	Pallet quantity	Quantity in package
1512x60x68x115	100	1
3010x60x68x115	100	1

Available variants

Code	Length [mm]	Type of equipment	Luminaire power [W]	Lumen luminaire [lm]	Efficacy [lm/W]	Colour temperature [K]	CRI/Ra
080171.3L01.111	1512	DALI	57	8600	151	4000	≥80
080171.3L02.211	3010	DALI	115	17200	150	4000	≥80
080171.5L01.111	1512	ED	57	8600	151	4000	≥80
080171.5L02.211	3010	ED	115	17200	150	4000	≥80
080173.3L01.111	1512	DALI	57	8600	151	4000	≥80
080173.3L02.211	3010	DALI	115	17200	150	4000	≥80
080173.5L01.111	1512	ED	57	8600	151	4000	≥80
080173.5L02.211	3010	ED	115	17200	150	4000	≥80

Compare selected

Luminous flux tolerance +/- 10%.
Power tolerance +/- 5%.
Lighting beam, light intensity distribution and light efficiency were examined in accordance with the EN ISO 17025:2005 norm for EN13032 norm series and the LM-79 norm.
Up-to-date product info and General Warranty Terms available on our website www.luglightfactory.com
Detailed information on luminous fluxes and powers for individual indexes are indicated on the product data sheet.
The parameters in the data sheet are given for Ta=25°C.
Colour temperature tolerance +/- 5%.
