PURELIGHT LUG DIRECT OPTI

Product description

Technical parameters

To download

Accessories

Explore services Customisation Support and contact
Other parameters available View variants
PURELIGHT LUG DIRECT OPTI
Specialized bactericidal and virucidal luminaire with T8 light sources. Surface mounted luminaire, emitting UV-C radiation with a wavelength of 253.7 nm.



Application

clinics, hospitals, hotels, kindergartens, laboratories, means of transport, nurseries, pharmaceutical and cosmetics industry, pharmacy, production facilities, schools, service companies

Mechanical data

Mounting
surface mounted
Body colour
white
Operating temperature range
0˚C ... +35˚C
RAL
9003
Body
powder-painted steel sheet; reflector: aluminum
Type
ASYMMETRICAL, ASYMMETRICAL with light source operating time counter, ASYMMETRICAL with light source operating time counter and remote control, SYMMETRICAL, SYMMETRICAL with light source operating time counter, SYMMETRICAL with light source operating time counter and remote control

Electrical data

Power
220-240V 50/60Hz
Includes light source
yes
Number of UV-C lamps
1, 2
Type of radiant tube [W]
30, 36
Luminaire power [W]
33 - 81
Type of equipment
PIR motion detector, remote control

Optical data

Way of lighting
direct
Type of optic
reflector

General data

Additional information
*maximum decontamination area for 90%; up to 99% - the exposure time should be extended 2 times; at 99.9% - the exposure time should be extended 3 times
Other remarks
Recommended mounting height of the luminaire from 2.1 m to 2.5 m. Ozone Free.
Warranty
2 years

Dimensions

Dimensions [mm] LxWxH Mounting dimensions [mm] L Pallet quantity Quantity in package Net weight [kg]
940x182x135 690 32 1 2.7
940x182x135 690 32 1 2.8
940x182x135 690 32 1 2.9
940x182x135 690 32 1 3
940x182x135 690 32 1 3.1
940x188x121 690 32 1 2.7
940x188x121 690 32 1 2.8
940x188x121 690 32 1 2.9
940x188x121 690 32 1 3
940x188x121 690 32 1 3.1
1250x182x135 1000 32 1 3.4
1250x182x135 1000 32 1 3.5
1250x182x135 1000 32 1 3.7
1250x182x135 1000 32 1 3.8
1250x188x121 1000 32 1 3.4
1250x188x121 1000 32 1 3.5
1250x188x121 1000 32 1 3.7
1250x188x121 1000 32 1 3.8
X

Available variants

Code
Luminaire power [W]
Type of radiant tube [W]
30
36
Type of equipment
PIR motion detector
remote control
Light distribution
asymmetric
symmetric
Clear Filters
Compare Code Number of UV-C lamps Light source operating time counter Type of equipment Type of radiant tube [W] Luminaire power [W] Max. decontamination area [m²] Decontamination time of external lamp [hh: mm] Light distribution UV-C radiant tube lifetime [h]
170011.1021.210 1 no 30 33 12 00:59 symmetric 9000
170011.1021.211 1 yes 30 33 12 00:59 symmetric 9000
170011.1021.211.920 1 yes PIR motion detector 30 35 12 00:59 symmetric 9000
170011.1021.213 1 yes remote control 30 35 12 00:59 symmetric 9000
170011.1021.220 1 no 30 33 12 00:59 asymmetric 9000
170011.1021.221 1 yes 30 33 12 00:59 asymmetric 9000
170011.1021.221.920 1 yes PIR motion detector 30 35 12 00:59 asymmetric 9000
170011.1021.223 1 yes remote control 30 35 12 00:59 asymmetric 9000
170011.1031.210 1 no 36 40 15 00:51 symmetric 9000
170011.1031.211 1 yes 36 40 15 00:51 symmetric 9000
Compare selected
Shown 10 / 32
Show all
Power tolerance +/- 10%.
Lighting beam, light intensity distribution and light efficiency were examined in accordance with the EN ISO 17025:2005 norm for EN13032 norm series and the LM-79 norm.
Up-to-date product info and General Warranty Terms available on our website www.luglightfactory.com
Detailed information on luminous fluxes and powers for individual indexes are indicated on the product data sheet.
The parameters in the data sheet are given for Ta=25°C.
Colour temperature tolerance +/- 5%.
Download Materials
Select and download the materials you are interested in
To download
Product sheet
Declarations and certificates
Light beam curves
Mounting instruction
Download selected
